- Interface: PCIe Gen2 X1
- Video Input: HDMI 1.4
- Audio Input: HDMI, Line In (3.5mm TRS)
- Video Output: HDMI 1.4
- Audio Output: HDMI, Line Out (3.5mm TRS)
- Max. Pass-Through: 2160p30, 1440p60, 1080p120
- Max. Recording: 1080p120, 2160p30, 1440p60
- Supported Resolution: 2160p, 1440p, 1080p, 720p
- Output Video Format: YUY2, NV12, RGB
- Recording Resolution and Max FPS: 3840x2160 - NV12/30; 2560x1440 - NV12/60, YUY/50; 1920x1080 - NV12/120, YUY/60, XRGB/30; 1280x720 - NV12/60, YUY/60, XRGB/60.
- Status Indicator: RED-power, BLUE-HDMI input, Mixing Slow Flashing-device running.
- System Requirement:
- Windows 10 x 64, PCI-E X1 slot
- For 4Kp30 or 1080p120 recording: Intel Core i5-6XXX / AMD, Ryzen 3 XXX or above, NVIDIA GTX 1060 / AMD RX 5700 or above, 8 GB RAM.
- For 1080p60 recording: Intel Core i7-3770 recommended, NVIDIA GeForce GTX 650 / AMD Radeon R7 250X or above, 4 GB RAM.
- Mac Pro, Mac OS High Sierra 10.15 and above, PCI-E X1 slot
- Dimensions: 151 x 121 x 22 mm
