- Fan Dimensions : 120 x 120 x 32 mm
- Fan Speed : 0 – 3,000 RPM
- Current : 0.1A/12V @1000 RPM, 0.2A/12V @2000 RPM, 0.8A/12V @3000 RPM
- Air Flow : 105.8 CFM
- Static Pressure : 8.14 mm-H2O
- Noise Level : <10.0* - 47.3 dBA - *Measuring below 10 dBA was not possible in our test chamber due to the noise floor
- Fan Blade Material : Fiberglass Reinforced Liquid Crystal Polymer (LCP)
- Fan Connector : Nexus Link Type-M
- Additional Sensors : Thermal + Positioning
- Included Accessories : 12x Case Fan Screws, 12x Radiator Fan Screws, 2x Nexus Link Type-M to Type-M Cables (300 mm), 1x Nexus Link Type-C to Type-M Cable (600 mm), 1x Nexus Link Type-M to Type-C Cable (600 mm), 1x Nexus Link Type-C to 4-Pin PWM Cable
- Software Support : HYTE Nexus
- Connection Channels : 3x Nexus Link Type-C, 1x 4-Pin PWM
- Maximum Devices – Single Channel : 18
- Maximum Devices – All Channels : 54
- Maximum Current – Single Channel : 8A/12V
- Maximum Current – All Channels : 15A/12V
- Maximum PSU Power Draw : Up to 180W depending on the number of connected Nexus Link devices
- ARGB LEDs : 6 qRGB Pixels (Also Function As Status Indicators)
- Input Connections : USB 2.0 Header, 6-Pin PCIe Power
- Software Support : HYTE Nexus
